KTK-R-3 | Bussmann by Eaton | series KTK-R fuse

Estimated Lead Time : 1-10 Working days

Manufacturer : Bussmann by Eaton

Part Number : KTK-R-3

Series : LIMITRON™ KTK-R

Fuse Class : Class CC (Rejection Style)

Current Rating : 3 A

Voltage Rating : 600 Vac

Interrupting Rating (AIC) : 200 kAIC RMS Symmetrical at 600 Vac

Response Characteristic : Fast-Acting / Current-Limiting

Body Material / Terminals : Melamine tube / Nickel-plated bronze ferrule end caps

Physical Dimensions : 13/32" × 1-1/2" (10.3 mm × 38.1 mm / 5AG)

Compliance & Standards : UL Listed (Std. 248-4, Class CC), CSA Certified (C22.2 No. 248.4), CE, RoHS

Eaton Bussmann LIMITRON™ KTK-R-3 Fast-Acting Fuse

The Bussmann KTK-R-3 is a high-performance Class CC fast-acting, current-limiting cartridge fuse engineered for specialized branch circuits and industrial control applications requiring up to 200 kAIC short-circuit protection.

Provides 10× better current limitation to protect downstream equipment from heavy short-circuits.

Rejection feature prevents standard non-rejection midget fuses from being inserted into Class CC holders.

Ideal for control panels, control circuit transformers, lighting circuits, and specialized industrial equipment.

Shipping weight : 1 Kg
